Ping i540 Irons Graphite LH
More Distance With Higher Launch
The Ping i540 Golf Irons are engineered for players seeking increased speed, distance and stopping power from a compact players-distance design. Combining a refined profile with advanced technology, the i540 delivers explosive ball speed while maintaining the control and precision better players demand.
Weight savings from a lighter, shallower face and covered cavity allow tungsten weighting to be positioned low in the head along the sole of the 4-7 irons. This lowers the centre of gravity to generate faster ball speeds, higher launch and improved stopping power when attacking the greens.
A forged variable-thickness maraging steel face is 9% thinner to increase flexing across the face. The design creates metal-wood-like bending through the transition areas in the sole and topline, producing faster ball speeds and higher maximum height for exceptional distance performance.
PING’s new inR-Air Technology introduces an internal airbag positioned behind the face within the cavity. This innovation enhances sound and feel at impact while allowing the face to flex freely for maximum performance.The addition of i-Beam Technology strengthens the 17-4 stainless steel body by adding structural support across the cavity. This improves stability and contributes to a more solid feel and pleasing acoustic at impact, while maintaining the powerful ball speeds expected from a players distance iron.
Ping i540 Irons Graphite LH
More Distance With Higher Launch
The Ping i540 Golf Irons are engineered for players seeking increased speed, distance and stopping power from a compact players-distance design. Combining a refined profile with advanced technology, the i540 delivers explosive ball speed while maintaining the control and precision better players demand.
Weight savings from a lighter, shallower face and covered cavity allow tungsten weighting to be positioned low in the head along the sole of the 4-7 irons. This lowers the centre of gravity to generate faster ball speeds, higher launch and improved stopping power when attacking the greens.
A forged variable-thickness maraging steel face is 9% thinner to increase flexing across the face. The design creates metal-wood-like bending through the transition areas in the sole and topline, producing faster ball speeds and higher maximum height for exceptional distance performance.
PING’s new inR-Air Technology introduces an internal airbag positioned behind the face within the cavity. This innovation enhances sound and feel at impact while allowing the face to flex freely for maximum performance.The addition of i-Beam Technology strengthens the 17-4 stainless steel body by adding structural support across the cavity. This improves stability and contributes to a more solid feel and pleasing acoustic at impact, while maintaining the powerful ball speeds expected from a players distance iron.
Ping i540 Irons Graphite LH
More Distance With Higher Launch
Forged Maraging Steel Face:
Forged variable-thickness maraging steel face is 9% thinner to increase flexing and generate faster ball speeds with higher maximum height.
Tungsten Weighting:
Tungsten weighting positioned along the sole of the 4–7 irons lowers the CG to increase launch, ball speed and stopping power.
inR-Air Technology:
Internal airbag system positioned behind the face improves sound and feel while allowing the face to flex freely for greater performance.
i-Beam Technology:
Structural beam within the cavity reinforces the club head, enhancing stability, sound and feel.
Players Distance Design:
Compact profile with powerful construction delivers the distance of a game-improvement iron with the control preferred by better players.
Ping i540 Irons Graphite LH
More Distance With Higher Launch
Iron Back: Hollow Cavity Back
Iron Size: Midsize
Iron Face: Forged Maraging Steel
Iron Construction: Forged
Shaft: Alta CB Blue
Grip: Tour Velvet 360 White Code
Handicap: Low-Mid
| Club | Length | Loft | Power Spec Loft | Retro Spec Loft | Lie Angle | Offset | Bounce | Swingweight |
|---|---|---|---|---|---|---|---|---|
| 4-Iron | 39 1/4" | 19.0° | 18.0° | 20.0° | 60.5° | 0.19" | 6.0° | D1 |
| 5-Iron | 38 1/2" | 22.0° | 21.0° | 24.0° | 61.0° | 0.16" | 7.0° | D1 |
| 6-Iron | 37 3/4" | 25.5° | 24.0° | 27.5° | 61.5° | 0.13" | 8.0° | D1 |
| 7-Iron | 37" | 29.0° | 27.5° | 31.0° | 62.0° | 0.10" | 9.0° | D1 |
| 8-Iron | 36 1/2" | 33.0° | 31.5° | 34.5° | 62.8° | 0.08" | 10.5° | D1 |
| 9-Iron | 36" | 37.0° | 36.0° | 38.0° | 63.5° | 0.06" | 12.0° | D1.5 |
| PW | 35 1/2" | 42.0° | 41.0° | 42.5° | 64.1° | 0.04" | 13.0° | D2 |
| UW | 35 1/2" | 47.0° | 46.0° | 47.5° | 64.1° | 0.03" | 13.0° | D2 |
| Shaft | Flex | Weight | Launch Angle |
|---|---|---|---|
PING AWT 3.0
 |
Regular | 96.0g | Mid High |
| Stiff | 102.0g | Mid | |
| X-Stiff | 114.0g | Low Mid | |
True Temper Dynamic Gold
 |
S300 | 124.0g | Low Mid |
| X100 | 124.0g | Low | |
True Temper Dynamic Gold 120
 |
S300 | 112.0g | Low |
| X100 | 114.0g | Low | |
True Temper Dynamic Gold Mid 100
 |
R300 | 105.0g | Mid |
| S300 | 105.0g | Mid | |
True Temper Dynamic Gold Mid 115
 |
S300 | 115.0g | Mid |
| X100 | 116.0g | Mid | |
Nippon N.S. Pro Modus 3 105
 |
Regular | 103.0g | Mid High |
| Stiff | 106.0g | Mid High | |
| X-Stiff | 112.0g | Mid High | |
Nippon N.S. Pro Modus 3 Tour 115
 |
Regular | 108.0g | Mid |
| Stiff | 109.0g | Mid | |
| X-Stiff | 110.0g | Mid | |
FST KBS Tour
 |
Regular | 104.0g | Mid |
| Stiff | 114.0g | Mid | |
| X-Stiff | 124.0g | Low Mid | |
PING ALTA CB Blue
 |
Soft Regular | 65.0g | High |
| Regular | 72.0g | Mid High | |
| Stiff | 82.0g | Mid | |
UST Recoil Dart
 |
65A (F2) | 61.0g | Mid |
| 75R (F3) | 72.0g | Mid | |
| 75S (F4) | 78.0g | Mid |
Ping i540 Irons Graphite LH
More Distance With Higher Launch
Galaxy Golf
Spain's Premier Custom Fit Retailer
We offer the choice of standard or custom fit options, where this product can be built to suit your personal requirements.
If you need any advice on custom fit options, please call our in-store professionals who are fully trained in personal custom fitting. You can call us on +34 868 171 981 or +34 966 775 856 or alternatively you can send a message from our Contact Us page.
As the leading custom fit retailer in Spain, we aim to deliver your custom fit order as quickly as possible. All custom fit equipment is built at the manufacturer's custom fit factory to ensure the highest quality of build, which may take up to 2-3 weeks as per the manufacturer's lead time.
